Original price was: $23,000.00.$20,800.00Current price is: $20,800.00.Set
KAVDO V Groove Cutter Machine Price depends on machine configuration, cutting capacity, control system, and application requirements. Designed for precise V-grooving on stainless steel, aluminum, and metal sheets, this machine helps improve bending quality and achieve clean decorative finishes. KAVDO provides reliable V groove cutter machines with stable performance, efficient operation, and competitive pricing for metal fabrication industries, including elevator panels, stainless steel processing, and architectural sheet metal applications.
100 in stock
| Item | Unit | 1250/3200 | 1250/4000 | 1500/4000 | 1500/5000 | 1500/6000 |
| Processing Length | mm | 3200 | 4000 | 4000 | 5000 | 6000 |
| Processing Width | mm | 1250 | 1250 | 1500 | 1500 | 1500 |
| Processing Thickness | mm | 0.4-5 | 0.4-5 | 0.4-5 | 0.4-5 | 0.4-5 |
| Main Knife Holder X-Axis Positioning Accuracy | mm | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 |
| Rear Material Y-Axis Positioning Accuracy | mm | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 |
| Positioning Accuracy Of Tool Holder Z Axis | mm | ±0.01 | ±0.01 | ±0.01 | ±0.01 | ±0.01 |
| Main Tool Holder X-Axis Machining Speed | m/min | 90 | 90 | 90 | 90 | 90 |
| Tool Holder Z Axis Machining Speed | m/min | 30 | 30 | 30 | 30 | 30 |
| Workbench Parallelism | mm | ±0.03 | ±0.03 | ±0.03 | ±0.03 | ±0.03 |
| Parallelism Of The Tool Holder Crossbeam Guide Rail | mm | ±0.05 | ±0.05 | ±0.05 | ±0.05 | ±0.05 |
| Pressure Cylinder Diameter | mm | 45 | 45 | 45 | 45 | 45 |
| Weight | kg | 6500 | 8000 | 9000 | 10000 | 12500 |
| Length | mm | 5500 | 6300 | 6300 | 7300 | 8300 |
| Width | mm | 2300 | 2300 | 2600 | 2600 | 2600 |
| Height | mm | 1680 | 1680 | 1680 | 1680 | 1680 |
The V Groove Cutter Machine Price is an important consideration for manufacturers looking to improve sheet metal bending accuracy and surface quality. KAVDO V groove cutter machines are designed for precision grooving operations on stainless steel, aluminum, copper, and other metal sheets, helping users create sharp and consistent bending lines.
With a rigid machine structure, high-performance cutting system, and user-friendly operation, KAVDO V groove cutter machines provide excellent processing efficiency for industries such as elevator manufacturing, kitchen equipment, architectural decoration, and custom metal fabrication.
KAVDO offers cost-effective V groove cutter machines with competitive V Groove Cutter Machine Price options for global metalworking customers. By combining precision, durability, and flexibility, KAVDO solutions help manufacturers achieve higher-quality bending results and improve their sheet metal production processes.
Heavy-duty CNC-machined worktable with ±0.03 mm flatness across the full working area, ensuring consistent groove depth and sheet stability during high-speed cutting.
FEA-optimized gantry cross beam with reinforced box-section design, providing maximum rigidity for vibration-free grooving at speeds up to 90 m/min.
Quick-change tool holder with ±0.05 mm guide rail flatness. Supports multiple insert angles and enables rapid swaps between groove profiles without recalibration.
Indexable carbide-tipped blades engineered for clean, burr-free V grooves. Multiple angle profiles available for standard and decorative grooving applications.
Specialized tooling kits for processing a wide range of alloy sheets including stainless steel, aluminum, copper, brass and titanium with optimized feed rates and depth control.
Upgrade from standard pneumatic to hydraulic clamping for enhanced holding force on thick or oversized sheets, ensuring zero sheet movement during multi-pass deep grooving.
A V grooving machine is an industrial machine used to create V-shaped grooves in sheet metal, cardboard, or other materials. It works by using a rotating V-shaped cutting tool that moves along the material surface, removing material to form precise grooves. These grooves allow the material to be folded easily without cracking, making it ideal for boxes, enclosures, signage, and packaging applications.
Our V grooving machines can process mild steel, stainless steel, aluminum, galvanized steel, copper, brass, and non-metals such as acrylic, PVC, cardboard, and corrugated board. Processing capacity depends on material type, thickness, and groove depth. Please refer to our specifications for specific material capabilities.
Standard groove angles include 30°, 45°, 60°, 90°, and 120°. The groove width and depth can be adjusted by changing the V-shaped cutting tool. Our machines support quick tool change systems for efficient switching between different groove configurations. Custom tooling can be provided for special applications.
V grooving removes material to create a thin hinge line, allowing manual or light-force folding without a press brake. It is ideal for thin materials, cardboard, and applications requiring sharp, precise folds. Press brake bending uses force to deform the material without removing it—better for thicker metals and high-volume production.
Standard models typically ship within 4-8 weeks. Custom configurations or large-format machines may require longer lead times. All our V grooving machines come with a comprehensive warranty covering major components including the cutting head and drive system. Extended warranty options are available.
We offer manual V grooving machines, semi-automatic models, and CNC V grooving machines. Manual models suit low-volume production; CNC models feature programmable controls for high precision and repeatability. We also provide single-head and multi-head configurations for different production requirements and material types.
Our V grooving machines typically handle sheet thickness from 0.3mm to 3mm for metals, with groove depths adjustable to suit your folding requirements. Maximum workpiece size varies by model—typically from 1000×2000mm up to 3000×6000mm or larger. Contact us for specifications tailored to your production needs.
Yes. Our CNC V grooving machines can produce straight grooves, curved grooves, and complex patterns through programmed paths. They support CAD/CAM file formats for accurate reproduction of designs. Optional features include automatic positioning and multi-axis control for intricate box and enclosure layouts.
Regular maintenance includes sharpening or replacing cutting tools, lubrication of guide rails and ball screws, inspection of drive systems and belts, and cleaning of chip removal systems. We provide detailed maintenance schedules and operator training. Annual professional inspections are recommended to ensure optimal performance.
Yes. We offer professional installation and commissioning, operator training on safe operation and programming, and comprehensive after-sales support including spare parts (cutting tools, blades, consumables, etc.) and technical assistance. Our global service network ensures prompt response when you need us.
At KAVDO, we believe in the power of collaboration. Our trusted partnerships with leading manufacturers in the metalworking industry enhance our capabilities and expand our offerings. Together, we strive to deliver innovative V Grooving Machine solutions that meet the evolving needs of our clients. Our commitment to excellence is reflected in the strong relationships we have built — precise groove depth, consistent quality, excellent for pre-bending preparation, and exceptional durability. Join us in celebrating our valued customers who trust KAVDO for their sheet metal V grooving and bending preparation needs.
The V grooving accuracy is outstanding — uniform groove depth and clean edges every time. Perfect preparation for press brake bending — reduces springback and improves bend quality. Highly recommend KAVDO V Grooving Machine for precision sheet metal work!
Pre-grooving with KAVDO has transformed our production. We achieve sharper bends, fewer rejects, and faster setup times. A must-have for sheet metal fabricators who demand quality bends and efficient workflow!
Factory direct, no middlemen, ensuring the best prices for our V Grooving Machine customers.
Quote Now
Enjoy peace of mind with a three-year warranty and free parts replacement for your V Grooving Machine.
Quote Now
Our multilingual team ensures efficient communication for all your V Grooving Machine needs.
Quote Now
The V Grooving Machines are delivered on time, ensuring our customers receive them promptly.
Quote Now
Comprehensive quality checks guarantee the quality of every KAVDO V Grooving Machine.
Quote Now
We provide prompt, localized service in multiple countries for your convenience.
Quote Now| Weight | 999 kg |
|---|---|
| Dimensions | 2020 × 1750 × 2439 mm |
| Brand |
KAVDO |
| Function |
Grooving |
| Lead Time |
30 Days |
| Payment Term |
LC ,TT |
| Price Term |
CIF ,DDP ,EXW ,FOB |
| Warranty |
3 Years |
